RVI Infinity Innovation specializes in custom-engineered industrial fiberscopes, known for their high quality and extremely small diameters, some as small as 0.37mm, using high-quality Image fiber bundles in their designs.
Key Product Features
-
Small Diameters: offers some of the smallest scopes in the industry, with diameters ranging from 0.37mm to 5mm.
-
Flexible and Rigid Options: The fiberscopes are available in flexible, semi-rigid, and rigid configurations to suit different inspection needs.
-
Image Quality: we utilize high-quality image fiber bundles for excellent picture resolution.
-
Customization: we specializes in custom designs, allowing for specific lengths, diameters, and adapters (e.g., Wolf, Storz, Olympus).
-
Durability: The scopes are designed for use in harsh environments, including aerospace, military, and general industrial inspection.
-
Illumination: The devices include illumination fibers to carry light to the inspection area and can be paired with a portable LED light source.
Accessories and Options
-
Eyepieces: Options include fixed eyepieces or focusable couplers that allow for manual focus adjustment.
-
Adapters: Various adapters are available for compatibility with other equipment, such as Wolf, Storz, ACMI, and Olympus systems.
-
Cameras: The fiberscopes can be connected to external cameras, such as the USB 2.0 CCD camera, for image recording and viewing on a monitor.
|
Ultrathin fiberscope
|
|
Diameter
|
Length
|
DOV
|
FOV
|
Resolution
|
|
ø 0.37mm
|
200mm
|
0°
|
70°
|
3 000 fibres
|
|
ø 0.37mm
|
500mm
|
0°
|
70°
|
3 000 fibres
|
|
ø 0.50mm
|
200mm
|
0°
|
70°
|
6 000 fibres
|
|
ø 0.50mm
|
500mm
|
0°
|
70°
|
6 000 fibres
|
|
ø 0.90mm
|
200mm
|
0°
|
70°
|
6 000 fibres
|
|
ø 0.90mm
|
500mm
|
0°
|
70°
|
6 000 fibres
|
|
ø 1.40mm
|
200mm
|
0°
|
70°
|
8 000 fibres
|
|
ø 1.40mm
|
500mm
|
0°
|
70°
|
8 000 fibres
|
|
ø 2.0mm
|
500mm
|
0°
|
70°
|
10 000 fibres
|
|
ø 2.0mm
|
1000mm
|
0°
|
70°
|
10 000 fibres
|
